2W005G, 2W01G, 2W02G, 2W04G, 2W06G, 2W08G, 2W10G PRODUCT INFORMATION

Glass Passivated Single-Phase Bridge Rectifier
vsh-img-product-image

pdf-icon-small Datasheet

FEATURES

UL recognition, file number E54214
Ideal for printed circuit boards
Typical IR less than 0.5 µA

APPLICATIONS

General purpose use in AC/DC bridge full wave? rectification for power supply, adapter, charger,? lighting ballaster on consumers, and home appliances? applications.
