SE30ND, SE30NG, SE30NJ PRODUCT INFORMATION

Surface-Mount Standard Rectifier
Automotive Grade Logovsh-img-product-image

FEATURES

Low-profile package- typical height of 0.88 mm
Leadless DFN package with side-wettable flanks suitable for customer AOI (Automatic Optical Inspection)
Ideal for automated replacement

APPLICATIONS

General purpose, power line polarity protection and rail-to-rail protection in consumer, industrial, and automotive applications.
