BYG24D, BYG24G, BYG24J PRODUCT INFORMATION

Fast Avalanche SMD Rectifier
Automotive Grade Logovsh-img-product-image

FEATURES

Low profile package
Ideal for automated placement
Glass passivated junction

APPLICATIONS

For use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer, automotive, and telecommunication.
