VS-HFA70EA120 PRODUCT INFORMATION

HEXFRED® Ultrafast Soft Recovery Diode, 70 A
vsh-img-product-image

pdf-icon-small Datasheet

FEATURES

Fast recovery time characteristic
Electrically isolated base plate
Antiparallel diodes

APPLICATIONS

This SOT-227 modules with HEXFRED® rectifier are in antiparallel configuration. The antiparallel configuration is used for simple series rectifier and high voltage application. The semiconductor in the SOT-227 package is isolated from the copper base plate, allowing for common heatsinks and compact assemblies to be built. These modules are intended for general applications such as HV power supplies, electronic welders, motor control and inverters.
