TA6F6.8A thru TA6F51A PRODUCT INFORMATION

Surface-Mount PAR® Transient Voltage Suppressors
Automotive Grade Logovsh-img-product-image

FEATURES

Very low profile - typical height of 0.95 mm
Junction passivation optimized design passivated anisotropic rectifier technology
TJ = 185 °C capability suitable for high reliability and automotive requirement

APPLICATIONS

Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, and telecommunication.
